Homepage >> Product Center >> Tilt sensors
Picture Description Range(±mm) Accuracy(±°) Resolution(°) Linearity(±°) Repeatability(±°) Operation Temp. (°C) Axial Output（Optional）

5

180

0.005

1

0.001

0.1

0.003

1

0.002

0.3

-100

650

Model: T223-10

Description: Extra-accuracy bi-axial Inclinometer

 10 0.005 0.001 0.003 0.002 -40 to 85℃ Bi-axial RS232,RS485,CAN

Model: T223-15

Description: Extra-accuracy bi-axial Inclinometer

 15 0.005 0.001 0.003 0.002 -40 to 85℃ Bi-axial RS232,RS485,CAN

Model: T223-30

Description: Extra-accuracy bi-axial Inclinometer

 30 0.005 0.001 0.003 0.002 -40 to 85℃ Bi-axial RS232,RS485,CAN

Model: T223-5

Description: Extra-accuracy bi-axial Inclinometer

 5 0.005 0.001 0.003 0.002 -40 to 85℃ Bi-axial RS232,RS485,CAN

Model: T220-10

Description: Bi-axial high accuracy inclinometer

 10 0.05 0.01 0.03 0.02 -40 to 85℃ Bi-axial RS232,RS485,CAN,CAN OPEN,SWITCH,Voltage,Current

Model: T220-90

Description: Bi-axial high accuracy inclinometer

 90 0.5 0.01 0.03 0.02 -40 to 85℃ Bi-axial RS232,RS485,CAN,CAN OPEN,SWITCH,Voltage,Current

Model: T220-60

Description: Bi-axial high accuracy inclinometer

 60 0.15 0.01 0.03 0.02 -40 to 85℃ Bi-axial RS232,RS485,CAN,CAN OPEN,SWITCH,Voltage,Current

Model: T220-45

Description: Bi-axial high accuracy inclinometer

 45 0.15 0.01 0.03 0.02 -40 to 85℃ Bi-axial RS232,RS485,CAN,CAN OPEN,SWITCH,Voltage,Current

Model: T220-30

Description: Bi-axial high accuracy inclinometer

 30 0.05 0.01 0.03 0.02 -40 to 85℃ Bi-axial RS232,RS485,CAN,CAN OPEN,SWITCH,Voltage,Current

Model: T220-15

Description: Bi-axial high accuracy inclinometer

 15 0.05 0.01 0.03 0.02 -40 to 85℃ Bi-axial RS232,RS485,CAN,CAN OPEN,SWITCH,Voltage,Current

Model: T220-5

Description: Bi-axial high accuracy inclinometer

 5 0.05 0.01 0.03 0.02 -40 to 85℃ Bi-axial RS232,RS485,CAN,CAN OPEN,SWITCH,Voltage,Current

Model: T210-360

Description: High accuracy inclinometer

 180 0.1 0.01 0.03 0.02 -40 to 85℃ Single axial RS232,RS485,CAN,CAN OPEN,SWITCH,Voltage,Current

Model: T210-180

Description: High accuracy inclinometer

 180 0.1 0.01 0.03 0.02 -40 to 85℃ Single axial RS232,RS485,CAN,CAN OPEN,SWITCH,Voltage,Current

Model: T210-90

Description: High accuracy inclinometer

 90 0.1 0.01 0.03 0.02 -40 to 85℃ Single axial RS232,RS485,CAN,CAN OPEN,SWITCH,Voltage,Current

Model: T210-60

Description: High accuracy inclinometer

 60 0.05 0.01 0.03 0.02 -40 to 85℃ Single axial RS232,RS485,CAN,CAN OPEN,SWITCH,Voltage,Current

Model: T210-45

Description: High accuracy inclinometer

 45 0.05 0.01 0.03 0.02 -40 to 85℃ Single axial RS232,RS485,CAN,CAN OPEN,SWITCH,Voltage,Current

Model: T210-30

Description: High accuracy inclinometer

 30 0.05 0.01 0.03 0.02 -40 to 85℃ Single axial RS232,RS485,CAN,CAN OPEN,SWITCH,Voltage,Current

Model: T210-15

Description: High accuracy inclinometer

 15 0.05 0.01 0.03 0.02 -40 to 85℃ Single axial RS232,RS485,CAN,CAN OPEN,SWITCH,Voltage,Current

Model: T210-10

Description: High accuracy inclinometer

 10 0.05 0.01 0.03 0.02 -40 to 85℃ Single axial RS232,RS485,CAN,CAN OPEN,SWITCH,Voltage,Current

Model: T210-5

Description: High accuracy inclinometer

 5 0.05 0.01 0.03 0.02 -40 to 85℃ Single axial RS232,RS485,CAN,CAN OPEN,SWITCH,Voltage,Current

Model: T211-5

Description: General industrial inclinometer

 5 0.5 0.05 0.3 0.2 -40 to 85℃ Single axial RS232,RS485,CAN OPEN,SWITCH,Voltage,Current

Model: T221-90

Description: Industrial Bi-axial Inclinometer

 90 1 0.05 0.3 0.2 -40 to 85℃ Bi-axial RS232,RS485,CAN,CAN OPEN,SWITCH,Voltage,Current

Model: T221-60

Description: Industrial Bi-axial Inclinometer

 60 0.5 0.05 0.3 0.2 -40 to 85℃ Bi-axial RS232,RS485,CAN,CAN OPEN,SWITCH,Voltage,Current

Model: T221-45

Description: Industrial Bi-axial Inclinometer

 45 0.5 0.05 0.3 0.2 -40 to 85℃ Bi-axial RS232,RS485,CAN,CAN OPEN,SWITCH,Voltage,Current

Model: T221-30

Description: Industrial Bi-axial Inclinometer

 30 0.5 0.05 0.3 0.2 -40 to 85℃ Bi-axial RS232,RS485,CAN,CAN OPEN,SWITCH,Voltage,Current

Model: T221-15

Description: Industrial Bi-axial Inclinometer

 15 0.5 0.05 0.3 0.2 -40 to 85℃ Bi-axial RS232,RS485,CAN,CAN OPEN,SWITCH,Voltage,Current

Model: T221-10

Description: Industrial Bi-axial Inclinometer

 10 0.5 0.05 0.3 0.2 -40 to 85℃ Bi-axial RS232,RS485,CAN,CAN OPEN,SWITCH,Voltage,Current

Model: T221-5

Description: Industrial Bi-axial Inclinometer

 5 0.5 0.05 0.3 0.2 -40 to 85℃ Bi-axial RS232,RS485,CAN OPEN,SWITCH,Voltage,Current

Model: T211-360

Description: General industrial inclinometer

 180 1 0.05 0.3 0.2 -40 to 85℃ Single axial RS232,RS485,CAN,CAN OPEN,SWITCH,Voltage,Current

Model: T211-180

Description: General industrial inclinometer

 180 1 0.05 0.3 0.2 -40 to 85℃ Single axial RS232,RS485,CAN,CAN OPEN,SWITCH,Voltage,Current

Model: T211-90

Description: General industrial inclinometer

 90 1 0.05 0.3 0.2 -40 to 85℃ Single axial RS232,RS485,CAN,CAN OPEN,SWITCH,Voltage,Current

Model: T211-60

Description: General industrial inclinometer

 60 0.5 0.05 0.3 0.2 -40 to 85℃ Single axial RS232,RS485,CAN,CAN OPEN,SWITCH,Voltage,Current

Model: T211-45

Description: General industrial inclinometer

 45 0.5 0.05 0.3 0.2 -40 to 85℃ Single axial RS232,RS485,CAN,CAN OPEN,SWITCH,Voltage,Current

Model: T211-30

Description: General industrial inclinometer

 30 0.5 0.05 0.3 0.2 -40 to 85℃ Single axial RS232,RS485,CAN,CAN OPEN,SWITCH,Voltage,Current

Model: T211-15

Description: General industrial inclinometer

 15 0.5 0.05 0.3 0.2 -40 to 85℃ Single axial RS232,RS485,CAN,CAN OPEN,SWITCH,Voltage,Current

Model: T211-10

Description: General industrial inclinometer

 10 0.5 0.05 0.3 0.2 -40 to 85℃ Single axial RS232,RS485,CAN,CAN OPEN,SWITCH,Voltage,Current

Model: T421-5

Description: Dynamic response inclinometer

 5 0.5 0.1 1 0.3 -40 to 85℃ Bi-axial CAN,Voltage

Model: T421-10

Description: Dynamic response inclinometer

 10 0.5 0.1 1 0.3 -40 to 85℃ Bi-axial CAN,Voltage

Model: T421-15

Description: Dynamic response inclinometer

 15 0.5 0.1 1 0.3 -40 to 85℃ Bi-axial CAN,Voltage

Model: T421-30

Description: Dynamic response inclinometer

 30 0.5 0.1 1 0.3 -40 to 85℃ Bi-axial CAN,Voltage

Model: T421-45

Description: Dynamic response inclinometer

 45 0.5 0.1 1 0.3 -40 to 85℃ Bi-axial CAN,Voltage
